ARKN Intel® Arc™ Pro B60 GDDR6 24GB
- GPU : Intel® Arc™ B60, Intel Xe2 Graphics Core Architecture
- GPU Peak TOPs : 197
- Memory : 24GB / 192bit GDDR6, 19Gbps
- Xe Cores : 20
- Ray Tracing Units: 20
- Intel XMX Engines: 160
- Power Consumption: 200w
Specifications
| SKU Number | 8357-00128 |
| Product Name | ARKN Intel®Arc™ Pro B60 |
| GPU | Intel® Arc™ B60, Intel Xe2 Graphics Core Architecture |
| Bus Support | Gen 5.0 x16 (x8 Electrical), with 4.0 Backwards Compatibility |
| GPU Peak Tops (Int8) | 197 |
| Xe Cores | 20 |
| Ray Tracing Units | 20 |
| Intel XMX Engines | 160 |
| Memory | 24GB/192bit GDDD6, 19Gbps |
| Memory Bandwidth | 456 GB/s |
| Display Support | 4 x DisplayPort, 2.1 |
| DisplayPort 2.1 Support | Yes, UHBR13.5 |
| External Power | 1 x 8 pin |
| Cooling Solution | Blower Fan / 2 ball bearing |
| Form Factor | 2 slot, ATX |
| Board Dimension | 260 x 130 (mm) |
| Board Power | 200W |
| System Requirement |
|
